Single Door Electromagnetic Lock with LED holding force up to 300 kg V2

69.00 лв. 69.0 BGN

69.00 лв.

Add to Cart


Single Door Electromagnetic Lock with LED with holding force up to 300 kg. And suitable for wooden, glass, metal and fireproof door.


Warranty (years): 2
Holding force (kg): 300
Current (mA): 500
Operating humidity(RH): 0% - 90% (non-condensing)
Operating temperature (°C): +10°C - +55°C
Voltage (V): 12 VDC
Dimensions (LxWxH mm): 250*48.5*25
Certificate: CE
Lock type: Fail Safe


До 14 дена можете да върнете поръчана стока
Цените са без ДДС
Купете сега, получете до 2 работни дни

Collinear Load Test 280kg

Suitable For Wooden Door,Glass Door,Metal Door,Fireproof Door.

LED Indicates the door Status.

Lock Status sensor(NO/NC/COM)

Anti-Residual Magnetism Designed.

Size - 250Lx48.8Wx27.9H(mm)

Armature Plate Dimension - 180Lx38.8Wx13.2H(mm)

LED - Red shows locked ;Green shows unlocked

Operating Temp - -20℃~+55℃

Warranty (years)

2

Holding force (kg)

300

Current (mA)

500

Operating humidity(RH)

0% - 90% (non-condensing)

Operating temperature (°C)

+10°C - +55°C

Voltage (V)

12 VDC

Dimensions (LxWxH mm)

250*48.5*25

Lock type

Fail Safe

Certificate

CE
